True Timber Kanati
MSRP: $7,149.00
Manufacturer: Suzuki
Condition: New
Description
In 1983, Suzuki introduced the world's first 4-wheel ATV. Today, Suzuki ATVs are everywhere. From the most remote areas to the most everyday tasks, you'll find the KingQuad powering a rider onward. Across the board, our KingQuad lineup is an exceptional group of ATVs.
Whether you’re working hard or getting away from it all, the 2022 Suzuki KingQuad 400ASi Camo helps you every step of the way. The fully automatic Quadmatic™ transmission has 2WD and 4WD modes to handle rough trail conditions while completing even the most demanding chores. Along with exceptional engine performance across the powerband, its high-performance iridium spark plug and Pulsed-secondary AIR-injection (PAIR) system helps provide outstanding fuel efficiency and clean emissions.
The KingQuad 400ASi Camo is not eligible for sale in California per California Air Resource Board (CARB) regulations.
Specifications
ENGINE
Engine
376cc (22.94 cubic in.), 4-stroke, air-cooled with SCAS, OHC single cylinder
Bore x Stroke
82.0 mm x 71.2 mm (3.228 in. x 2.803 in.)
Compression Ratio
9.0:1
Fuel System
Suzuki electronic fuel injection
Starter
Electric
Lubrication
Wet sump
DRIVETRAIN
Transmission
Automatic variable ratio (V-belt), with high/low-range and reverse
Clutch
Dry shoe, automatic, centrifugal type
Driven Wheels
2WD and 4WD
Final Drive
Shaft drive
CHASSIS
Suspension Front
Independent, double wishbone, coil spring, oil damped
Suspension Rear
Swingarm type, coil spring, oil damped
Brakes Front
Disc brakes, twin rotors
Brakes Rear
Single drum brake
Tires Front
AT25 x 8-12, tubeless type x 2
Tires Rear
AT25 x 10-12, tubeless type x 2
Fuel Tank Capacity
16.0 L (4.2 US gal.)
Color
True Timber Kanati Camouflage
ELECTRICAL
Ignition
Electronic ignition (transistorized)
Headlight
12V 35/35W (HS1) × 2
Tail Light
12V 21/5W
DIMENSIONS
Overall Length
2060 mm (81.1 in.)
Overall Width
1145 mm (45.1 in.)
Overall Height
1220 mm (48.0 in.)
Wheelbase
1270 mm (50.0 in.)
Ground Clearance
250 mm (9.8 in.)
Seat Height
840 mm (33.1 in.)
Curb Weight
265 kg (628 lb.)
WARRANTY
Warranty
12-month limited warranty
Extension
Longer coverage periods with other benefits are available through Suzuki Extended Protection (SEP)
Features
KEY FEATURES
- Powerful, fuel-injected, 4-stroke engine is easy on gas
- Large fuel tank and plush seat deliver extended, comfortable riding range
- Fender-mounted shifter controls the QuadMatic™ transmission
- Select 2WD or 4WD via a handlebar-mounted lever
- Rugged bodywork and full racks to tackle any task
- Ready for outdoor action with True Timber Kanati pattern camouflaged bodywork
ENGINE FEATURES
- The KingQuad 400ASi’s fuel-injected 376cc four-stroke, four-valve engine produces efficient power and driveablity.
- Suzuki's class-leading fuel injection smooths power output, especially in the mid-to-high range, and provides excellent cold starting. The system uses 3-D maps for optimum ignition, creating responsive yet environmentally compliant performance.
- Suzuki Advanced Cooling System (SACS) uses an oil cooler and thermostat-controlled cooling fan to shed engine heat during hard work or cargo hauling.
- Push-button electric starting has a start-in-gear function allowing starting without shifting to neutral (as conditions permit).
- The Engine Control Unit (ECU) has slip control logic, which adjusts fuel injector duration and timing to improve drivability and grip in loose/slippery conditions.
- Highly efficient iridium spark plug contributes to better combustion, cleaner emissions, and longer plug life. Engine starting under low temperature is also improved.
- Pulsed-secondary AIR-injection (PAIR) system and catalyst-equipped exhaust system help the ATV comply with Environmental Protection Agency (EPA) emission standards while maintaining a high level of performance.
TRANSMISSION FEATURES
- The QuadMatic™ transmission is a fully automatic, CVT (continuously variable transmission) with selectable high/low sub-transmission and reverse for maximum traction and fuel efficiency.
- Automotive gate-type gearshift lever lets you conveniently choose high or low range, neutral, or reverse.
- Select 2WD and 4WD with the flip of a handlebar-mounted lever. The shaft drive system is reliable and durable and is nearly maintenance-free.
- Torque-sensing limited-slip front differential provides maximum traction and light steering when in 4WD mode.
- An advanced engine-braking system minimizes free-wheeling with the throttle off to help control the ATV during descents.
- The ECU has a Reverse Mode that monitors vehicle speed so higher engine RPM can be used when getting out of mud or loose soil in reverse mode.
CHASSIS FEATURES
- Sporty, camouflage coated bodywork features sharply angled, high-clearance fenders.
- Suzuki's plush T-shaped seat delivers rider mobility during sport or difficult terrain riding. Overall length is under 82 inches (208 cm), so the KingQuad fits into a 6.5-foot truck bed for easy transportation.
- Independent front A-arm suspension offers smooth performance and remarkable ground clearance with 6.7 inches (170.1 mm) of wheel travel.
- A swingarm rear suspension with 6.7 inches (170.1 mm) of wheel travel and twin shock absorbers provides agile handling and plush riding.
- Dual front hydraulic disc brakes feature calipers with large, 34mm pistons and wide brake-pad surface area for increased stopping power and outstanding durability. Lightweight and strong plastic skid plates are sturdy to withstand trail pounding, yet slippery to let obstacles slide below.
- Lightweight and strong plastic skid plates are sturdy to withstand trail pounding, yet slippery to let obstacles slide below.
- Large, 25-inch Carlisle tires with aggressive tread offer consistent traction in wet conditions, yet make for a quiet, smooth ride on hard-packed trails.
- The KingQuad 400ASi Camo rides on strong steel wheels with a durable, powder-coated matte black finish.
UTILITY/CONVENIENCE FEATURES
- Dual 35-watt headlights (with high and low settings) are part of the distinctive KingQuad grille appearance. Bright taillight helps make the ATV visible in dark conditions.
- Heavy-duty front and rear cargo racks let you take advantage of the ATV’s superb load capabilities. Wrinkle paint finish on the racks and front bumper is durable and scratch resistant.
- LCD instrumentation includes speedometer, odometer, trip meter, hour meter, clock, fuel gauge and indicators for reverse, neutral, oil and FI (fuel injection).
- Automotive-style DC power outlet is included on front fender.
- Winch-ready mounts and wire conduit make winch installation simple.
- Large, 4.2 gallon (16.0 L) fuel tank provides outstanding riding range.
- Full floorboards with integrated raised footpegs provide protection.
SPECIAL FEATURES
- 12-month limited warranty. Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).*
- *Subject to separate coverage for certain parts and the exclusions and limitations described in the New ATV Limited Warranty.
- A variety of Suzuki Genuine Accessories are available, including winches, windshield, front and rear bumpers, snowplow, aluminum skid pans, rack extensions, utility box, and more.
- Minimum Operator Age: 16 Years Old
- This model is not eligible for sale in California per California Air Resource Board (CARB) regulations.
All inventory listed is subject to availability and prior sale. Manufacturer's Suggested Retail Price (MSRP) if shown for a vehicle excludes set-up, freight, taxes, title, licensing or other dealer charges, and is subject to change. Individual prices may vary. Please request a quote for specific pricing.
